VEVOR Electric Compressor Motor, 3/4 HP, Rated Speed 1725 RPM Single Phase Electric Motor, AC 115V 230V Air Compressor Motor
Highlights:
1.3/4 HP Electric Motor: The compact and small-sized AC motor features output 0.75 HP, 56C Frame, and single phase. Gasketed capacitor housing and conduit boxes protect all environments.
2.High Working Efficiency: The electric motor 56C can run at the maximum speed of 1745 RPM, high working efficiency, Voltage: 115/230V 60 HZ, shaft diameter: 5/8" / 1.6 cm, shaft length: 1.88" / 4.8 cm, upper hardness shaft is more durable.
3.Sturdy Steel Housing: The compressor duty motor is made of high-quality steel material. The firm and solid material protects the engine well, and the smooth appearance is easy to clean; it includes the mounting bracket, and the bracket structure is stable and easy to use.
4.High-Speed Cooling Fan: Big fan at one end cools the motor in hours' running, even in dusty or damp environments, reducing energy costs or overheads, reducing the running temperature, increasing winding lifetimes.
5.Multiple Application: The electric motors are commonly used in industrial and agricultural production, transportation, commercial and household appliances, and other fields. For instance, the matching of water pumps, agricultural machinery, etc.
Details:
![]()
![]()
![]()
![]()
![]()
![]()
![]()
![]()
![]()
![]()
![]()
![]()
![]()
![]()
![]()
![]()
![]()
1.3/4 HP Electric Motor: The compact and small-sized AC motor features output 0.75 HP, 56C Frame, and single phase. Gasketed capacitor housing and conduit boxes protect all environments.
2.High Working Efficiency: The electric motor 56C can run at the maximum speed of 1745 RPM, high working efficiency, Voltage: 115/230V 60 HZ, shaft diameter: 5/8" / 1.6 cm, shaft length: 1.88" / 4.8 cm, upper hardness shaft is more durable.
3.Sturdy Steel Housing: The compressor duty motor is made of high-quality steel material. The firm and solid material protects the engine well, and the smooth appearance is easy to clean; it includes the mounting bracket, and the bracket structure is stable and easy to use.
4.High-Speed Cooling Fan: Big fan at one end cools the motor in hours' running, even in dusty or damp environments, reducing energy costs or overheads, reducing the running temperature, increasing winding lifetimes.
5.Multiple Application: The electric motors are commonly used in industrial and agricultural production, transportation, commercial and household appliances, and other fields. For instance, the matching of water pumps, agricultural machinery, etc.
Details:
3/4 HP Electric Motor 56C Frame Single Phase
The listing is about electric motor F56C 3/4S4C-C, an electrical machine that converts electrical energy into mechanical energy. It is a 0.75 hp SHDC electric motor that is commonly used to match water pumps, agricultural machinery, and general equipment. A 115/230 volt electric motor that turns at 1745 RPM. A single-phase motor that has a rigid base and 5/8" keyed shaft.
- 3/4 HP Electric Motor
- High Working Efficiency
- Sturdy Steel Housing
- High-Speed Cooling Fan
- Multiple Application
VEVOR is a leading brand that specializes in equipment and tools. Along with thousands of motivated employees, VEVOR is dedicated to providing our customers with tough equipment & tools at incredibly low prices. Today, VEVOR has occupied markets of more than 200 countries with 10 million plus global members.
Why Choose VEVOR?
- Premium Tough Quality
- Incredibly Low Prices
- Fast & Secure Delivery
- 30-Day Free Returns
- 24/7 Attentive Service
VEVOR is a leading brand that specializes in equipment and tools. Along with thousands of motivated employees, VEVOR is dedicated to providing our customers with tough equipment & tools at incredibly low prices. Today, VEVOR has occupied markets of more than 200 countries with 10 million plus global members.
Why Choose VEVOR?
- Premium Tough Quality
- Incredibly Low Prices
- Fast & Secure Delivery
- 30-Day Free Returns
- 24/7 Attentive Service
Powerful Motor
The high-power motor has a single-phase motor and 115/230V voltage, which can save energy in a long time, reduce energy costs or overhead. Move effortlessly.
High Performance
The electric motor 56C runs at 3/4 HP, and the maximum speed is 1745 RPM, Synchronous speed: 1800 RPM, high hardness shaft is more durable.
Sturdy & Durable Construction
The motor housing is made of durable metal material, robust and reliable, with strength and durability, corrosion resistance, and smooth surface provides comfortable use.
Mounting Bracket Included
A sturdy mounting bracket is included in the package to improve the motor's stability and reduce friction, ball-bearing systems are also suitable for many applications.
Fully Enclosed Fan
Even in dusty or damp environments, the big fan at one end cools the motor in hours' running to reduce the energy costs and the running temperature.
Wide Application
The electric motor is suitable for air compressors, medical equipment refiners, metal cutting machine tools, pumps, fans, transport machinery mixers, food machinery, etc.
Specifications
- Model: F56C 3/4S4C-C
- Phase: Single Phase
- Horsepower: 3/4 HP
- Voltage: 115/230V
- Amps: 10.89/5.31A
- SF Amps: 12.52/6.15A
- Frequency: 60 Hz
- Rated Speed: 1745 RPM
- Synchronous Speed: 1800 RPM
- Frame: 56C Frame
- Shaft Diameter: 5/8" / 1.6 cm Keyed Shaft
- Shaft Length: 1.875"/4.8 cm
- Rotation: CW-CCW
- IP Rating: IP 55
- Service Factor: 1.15
- ENCL: TEFC
- Insulation Class: F
- Pole: 4
- NEMA: L
- AMB: 40 °C / 104 °F
- Mounting Type: Rigid/Flange installation
- Reversible/Non-Reversible: Reversible
- AC Motor Type: Induction Motor
- Motor Size(L x W x H): 12 x 8 x 8''/30.48 x 20.32 x 20.32 cm
Package Content
- 1 x Electric Motor
VEVOR is a leading brand that specializes in equipment and tools. Along with thousands of motivated employees, VEVOR is dedicated to providing our customers with tough equipment & tools at incredibly low prices. Today, VEVOR has occupied markets of more than 200 countries with 10 million plus global members.
Why Choose VEVOR?
- Premium Tough Quality
- Incredibly Low Prices
- Fast & Secure Delivery
- 30-Day Free Returns
- 24/7 Attentive Service
VEVOR is a leading brand that specializes in equipment and tools. Along with thousands of motivated employees, VEVOR is dedicated to providing our customers with tough equipment & tools at incredibly low prices. Today, VEVOR has occupied markets of more than 200 countries with 10 million plus global members.
Why Choose VEVOR?
- Premium Tough Quality
- Incredibly Low Prices
- Fast & Secure Delivery
- 30-Day Free Returns
- 24/7 Attentive Service
3/4 HP Electric Motor 56C Frame Single Phase
The listing is about electric motor F56C 3/4S4C-C, an electrical machine that converts electrical energy into mechanical energy. It is a 0.75 hp SHDC electric motor that is commonly used to match water pumps, agricultural machinery, and general equipment. A 115/230 volt electric motor that turns at 1745 RPM. A single-phase motor that has a rigid base and 5/8" keyed shaft.
- 3/4 HP Electric Motor
- High Working Efficiency
- Sturdy Steel Housing
- High-Speed Cooling Fan
- Multiple Application
Powerful Motor
The high-power motor has a single-phase motor and 115/230V voltage, which can save energy in a long time, reduce energy costs or overhead. Move effortlessly.
High Performance
The electric motor 56C runs at 3/4 HP, and the maximum speed is 1745 RPM, Synchronous speed: 1800 RPM, high hardness shaft is more durable.
