VEVOR 1.5HP Electric Motor
Highlights:
1.Single Phase Electric Motor: This electric compressor motor runs at 1.5 HP. Type: SHDC; Phase: Single Phase, 2 Pole; Voltage: 115/230V; Full Load Amps: 14.2/7.1A; Frequency: 60 Hz; Frame: 56C Frame; Rotation: CW - CCW(Reversible); AC Motor Type: Induction Motor. Push your machine to the limits with this well-balanced motor!
2.Excellent Working Efficiency: The single phase electric motor features a 3450 RPM rated speed, and 3600 RPM synchronous speed. Shaft Diameter: 5/8 in / 1.6 cm Keyed Shaft; Shaft Length: 1.875 in / 4.8 cm; Service Factor: 1.15; Insulation Class: F. The upper hardness shaft is more durable. Works above and beyond while maintaining high performance.
3.Sturdy Steel Construction: The 1.5 HP compressor motor shell is made of premium steel material. The robust and reliable body can guard the internal circuit well against overheating. The attached steel bracket also offers excellent stability. High-quality capacitors and ball bearings ensure long service life.
4.High-Speed Cooling Fan: Enclosure Type: TEFC(Totally Enclosed Fan Cooled). The big fan at one end cools the 1.5 HP electric motor single phase for hours while running, even in dusty or damp environments. Multiple heat dissipation strips guard chips and objects against dropping into the motor and causing accidents. Power and protection that you can trust.
5.Apply in Multiple Sectors: The air compressor motor 3450 rpm is commonly used in industrial and agricultural production, transportation, commercial and household appliances, and other fields. For instance, the matching of water pumps, agricultural machinery, etc. Ensure our motor matches the specific specifications listed on your compressor before purchase.
Details:
![]()
![]()
![]()
![]()
![]()
![]()
![]()
![]()
![]()
![]()
![]()
![]()
![]()
![]()
![]()
![]()
![]()
![]()
![]()
![]()
1.Single Phase Electric Motor: This electric compressor motor runs at 1.5 HP. Type: SHDC; Phase: Single Phase, 2 Pole; Voltage: 115/230V; Full Load Amps: 14.2/7.1A; Frequency: 60 Hz; Frame: 56C Frame; Rotation: CW - CCW(Reversible); AC Motor Type: Induction Motor. Push your machine to the limits with this well-balanced motor!
2.Excellent Working Efficiency: The single phase electric motor features a 3450 RPM rated speed, and 3600 RPM synchronous speed. Shaft Diameter: 5/8 in / 1.6 cm Keyed Shaft; Shaft Length: 1.875 in / 4.8 cm; Service Factor: 1.15; Insulation Class: F. The upper hardness shaft is more durable. Works above and beyond while maintaining high performance.
3.Sturdy Steel Construction: The 1.5 HP compressor motor shell is made of premium steel material. The robust and reliable body can guard the internal circuit well against overheating. The attached steel bracket also offers excellent stability. High-quality capacitors and ball bearings ensure long service life.
4.High-Speed Cooling Fan: Enclosure Type: TEFC(Totally Enclosed Fan Cooled). The big fan at one end cools the 1.5 HP electric motor single phase for hours while running, even in dusty or damp environments. Multiple heat dissipation strips guard chips and objects against dropping into the motor and causing accidents. Power and protection that you can trust.
5.Apply in Multiple Sectors: The air compressor motor 3450 rpm is commonly used in industrial and agricultural production, transportation, commercial and household appliances, and other fields. For instance, the matching of water pumps, agricultural machinery, etc. Ensure our motor matches the specific specifications listed on your compressor before purchase.
Details:
1.5 HP 3450 RPM Electric Motor
Single Phase & TEFC Enclosure & Fast Heat Dissipation
VEVOR's single phase electric motor is rated at 1.5 HP 3450 RPM and can be connected to 115/230V incoming power devices. This general purpose electric motor conforms to the standard for high hardness and performance, which is well suited for water pumps, agricultural machinery, and general equipment. Built tough to work tough, Our motor will have your equipment roaring for the next job!
- Single Phase Electric Motor
- Excellent Working Efficiency
- Sturdy Steel Construction
- High-Speed Cooling Fan
VEVOR is a leading brand that specializes in equipment and tools. Along with thousands of motivated employees, VEVOR is dedicated to providing our customers with tough equipment & tools at incredibly low prices. Today, VEVOR has occupied markets of more than 200 countries with 10 million plus global members.
Why Choose VEVOR?
- Premium Tough Quality
- Incredibly Low Prices
- Fast & Secure Delivery
- 30-Day Free Returns
- 24/7 Attentive Service
VEVOR is a leading brand that specializes in equipment and tools. Along with thousands of motivated employees, VEVOR is dedicated to providing our customers with tough equipment & tools at incredibly low prices. Today, VEVOR has occupied markets of more than 200 countries with 10 million plus global members.
Why Choose VEVOR?
- Premium Tough Quality
- Incredibly Low Prices
- Fast & Secure Delivery
- 30-Day Free Returns
- 24/7 Attentive Service
High-Performance Motor
1.5hp air compressor motor allows you to conserve energy over extended periods, reducing power costs and overheads, and maintaining a high working efficiency.
3450 RPM High Speed
The motor for air compressor runs at 3450 RPM, Synchronous Speed: 3600 RPM. Our high-quality steel shaft characterized by its low rotating noise and stable operation.
Rugged & Durable Construction
The 3450 rpm electric motor housing is constructed from reliable metal material, which features robustness, strength, and durability, offering a long service life.
Rigid Mounting Bracket
The general purpose electric motor comes with a sturdy mounting bracket, which enhances the motor's stability and reduces friction.
Fully Enclosed Fan
A built-in silent cooling fan will quickly dissipate heat while running for a long time. With multiple heat dissipation holes, effectively guarding the motor's body.
Wide Application
This motor 56c frame is suitable for air compressors, medical equipment, metal cutting machines, pumps, fans, transport machinery, food machinery, etc.
Specifications
- Type: SHDC
- Phase: Single Phase, 2 Pole
- Horsepower: 1.5 HP
- Voltage: 115/230V
- Full Load Amps: 14.2/7.1A
- Frequency: 60 Hz
- Rated Speed: 3450 RPM
- Synchronous Speed: 3600 RPM
- Frame: 56C Frame
- Shaft Diameter: 5/8 in / 1.6 cm Keyed Shaft
- Shaft Length: 1.875 in / 4.8 cm
- Rotation: CW - CCW(Reversible)
- ENC: TEFC
- Service Factor: 1.15
- Insulation Class: F
- AC Motor Type: Induction Motor
- IP Rating: IP55
- Efficiency: 80%
- Reversible/Non-Reversible: Reversible
- Mounting Type: Rigid/Flange Installation
- Motor Size(L x W x H): 13 x 7 x 8.5 in / 33.02 x 17.78 x 21.59 cm
Package Content
- 1 x Electric Motor
VEVOR is a leading brand that specializes in equipment and tools. Along with thousands of motivated employees, VEVOR is dedicated to providing our customers with tough equipment & tools at incredibly low prices. Today, VEVOR has occupied markets of more than 200 countries with 10 million plus global members.
Why Choose VEVOR?
- Premium Tough Quality
- Incredibly Low Prices
- Fast & Secure Delivery
- 30-Day Free Returns
- 24/7 Attentive Service
VEVOR is a leading brand that specializes in equipment and tools. Along with thousands of motivated employees, VEVOR is dedicated to providing our customers with tough equipment & tools at incredibly low prices. Today, VEVOR has occupied markets of more than 200 countries with 10 million plus global members.
Why Choose VEVOR?
- Premium Tough Quality
- Incredibly Low Prices
- Fast & Secure Delivery
- 30-Day Free Returns
- 24/7 Attentive Service
1.5 HP 3450 RPM Electric Motor
Single Phase & TEFC Enclosure & Fast Heat Dissipation
VEVOR's single phase electric motor is rated at 1.5 HP 3450 RPM and can be connected to 115/230V incoming power devices. This general purpose electric motor conforms to the standard for high hardness and performance, which is well suited for water pumps, agricultural machinery, and general equipment. Built tough to work tough, Our motor will have your equipment roaring for the next job!
- Single Phase Electric Motor
- Excellent Working Efficiency
- Sturdy Steel Construction
- High-Speed Cooling Fan
High-Performance Motor
1.5hp air compressor motor allows you to conserve energy over extended periods, reducing power costs and overheads, and maintaining a high working efficiency.
3450 RPM High Speed
The motor for air compressor runs at 3450 RPM, Synchronous Speed: 3600 RPM. Our high-quality steel shaft characterized by its low rotating noise and stable operation.
Rugged & Durable Construction
The 3450 rpm electric motor housing is constructed from reliable metal material, which features robustness, strength, and durability, offering a long service life.
Rigid Mounting Bracket
The general purpose electric motor comes with a sturdy mounting bracket, which enhances the motor's stability and reduces friction.
Fully Enclosed Fan
A built-in silent cooling fan will quickly dissipate heat while running for a long time. With multiple heat dissipation holes, effectively guarding the motor's body.
